Huawei AP Panel Fiber Optic

Huawei fiber-capable access points (APs) support hybrid optical-electrical uplinks, plug-and-play optical modules, and flexible deployment for high-speed indoor wireless networks.

Key Huawei Fiber-Optic AP Models

AirEngine 5762-15HW

• Wi-Fi 6 (802.11ax) wall plate AP with 2 x 2 MIMO, supporting 2.4 GHz and 5 GHz bands at up to 2.975 Gbit/s .
• Features a 2.5GE optical uplink port compatible with GE optical, hybrid, or GPON modules, plus 4 GE electrical downlink ports .
• Supports hybrid cables for simultaneous data transmission and PoE over distances exceeding 1 km, ideal for SMEs, hospitals, and cafés . AirEngine 5773-23HW
• Wi-Fi 7 (802.11be) wall plate AP with 4 spatial streams, delivering up to 3.57 Gbit/s .
• Supports hybrid cables and plug-and-play optical fibers with an uplink optical port capable of PoE over distances up to 2 km .
• Designed for SMB workplaces, higher education, and hospitals, with dual-band smart antennas for interference suppression and high-quality coverage . AirEngine 5773-25HW
• Wi-Fi 7 wall plate AP with four spatial streams and peak data rate of 3.57 Gbit/s, supporting 2.4 GHz and 5 GHz bands .
• Includes one 2.5GE optical uplink port, one 2.5GE electrical uplink port, eight GE downlink ports, and a USB port .
• Built-in optical module allows plug-and-play fiber installation, reducing costs and enabling hybrid optical-electrical deployment for high-traffic applications like AR/VR collaboration .

Fiber Management and Installation

Huawei APs with fiber support often use a fiber management tray to organize and protect optical fibers . Key installation guidelines include:

• Coiling direction: Clockwise is recommended.
• Maximum coiling length: 4 m for 2 mm diameter fibers; 0.75–1 m for 3 mm pigtails depending on stripping .
• Layered coiling: Coil fiber layer by layer, securing near the fiber splicing rod with foam adhesive.
• Connector insertion: Route the fiber to the AP and insert the LC connector into the AP's flange port .

Deployment Advantages

• Hybrid cable support allows simultaneous data and power delivery over long distances, reducing the need for separate electrical wiring .
• Plug-and-play optical modules simplify installation and reduce operational costs.
• Smart antennas and MIMO technology enhance coverage, reduce interference, and support high user concurrency.
• Suitable for SMEs, hospitals, educational institutions, hotels, and high-density indoor environments. Huawei fiber-capable APs provide a flexible, high-speed, and cost-efficient solution for indoor wireless networks, combining optical uplinks, PoE support, and simplified fiber management for reliable deployment.
